Follow these step-by-step instructions to safely install your Jumpzylla trampoline. Assembly is simple, but we recommend two adults and allocating at least 2–3 hours depending on the trampoline size.
📺 Need a visual guide? Watch our official Installation Video
You can also download a pdf version of our installation manual on this page!
📦 What's in the Box?
Your trampoline kit includes the following parts:
- Frame tubes
- Steel T-connectors
- W-shaped legs & leg extensions
- Jumping mat with springs
- Enclosure net & poles
- Plastic safety caps
- Fiberglass rods for the net
- Screws, spring tools, ladder & nuts
- Reversible spring pad cover
- User manual & instructions
✅ Refer to the Part List on pages 6–7 of the manual to verify quantities based on trampoline size (8FT to 16FT) .
🚧 Before You Start
- Choose a flat, open area (avoid uneven or sloped ground)
- Keep at least 6 ft of clearance around the trampoline
- Wear gloves and closed shoes
- Do not assemble in strong wind or rain
Do NOT bury the trampoline or place it on asphalt, concrete, or slippery surfacesJz Installing manual 20….
🔩 Assembly Steps
🧱 Frame & Legs (Steps 1–3)
- Insert leg extensions into W-shaped legs. Bumps must face outward and stick through the holes.
- Connect frame tubes to the T-connectors to form a full circle.
- Attach the legs to the frame. Two people may be needed to snap the frame together.
🏃 Jumping Mat (Steps 4–5)
- Lay the mat inside the frame. Ensure the Jumpzylla logo faces up.
- Attach springs in an X pattern to evenly distribute tension. Use the included spring tool and take care not to pinch your fingers.
🧱 Pole & Net Assembly (Steps 6–8)
- Insert bottom pole, plastic pad, and leg extension, then fasten with screws.
- Connect the plastic T-connector to the top of the pole. Ensure bumps click into place.
- Insert the fiberglass rods through the net’s top edge and into the T-connectors.
🛡️ Net & Safety Padding (Steps 9–10)
- Attach the safety net to the springs using the clips and snap hooks.
- Cover springs with the spring pad and secure using Velcro straps. Pad should fully cover all metal parts.
⚠️ Tip: If the zipper won’t close properly, check that the thread is looped all the way around the netJz Installing manual 20….
🎨 Double-Sided Spring Cover (Page 11)
Choose your style — flip the reversible cover to show off either color. Both sides are UV- and weather-resistant.
🪜 Step Ladder (Steps 11–12)
- Connect the ladder pipes and slide the steps on. Secure with screws and nuts.
- Hook the ladder onto the trampoline frame under the padding cover.
✔️ Final Checklist
✅ All legs are fully inserted and secure
✅ Springs are evenly installed and tight
✅ Net is attached, fully zipped, and clipped
✅ Ladder is firmly hooked and secure
✅ No loose bolts, tools, or packaging left inside
